'tbd' Apple-1 - number 84 in the Registry

7 pictures published.

Version

2nd batch NTI

Handwritten number, stamp, label

Label 4062, no number on the back

Location

USA, California

Verification

According to pictures.

Condition

Working

Description

The circuit board has been signed by Steve Wozniak.
The extra connector has a remarkable background (information is Elmar Baum's son): My father worked on the Apple II power supply with Rod Holt, and the extra connector (and extra diodes) on his board was used to power Apple IIs before that switching supply was completed.


History

From the owner:
This board was from a batch of 25 which were never sold and in a stack of boxes on Steve Jobs’ desk. Steve allowed employees to take them as the company had stopped selling Apple 1s in favor of Apple IIs. Elmer Baum (Apple Employee #34 and financier of the 1st run of Apple 1s) took 2 boards. My father, an engineer in Silicon Valley, was given one of these boards and kept it for many years.
It is up for auction in December 2019 at Bonhams NYC.


Auctioned

no auction


Components

White ceramic CPU MCS 6502 Motorola (date code 11/77), plastic PIA Rockwell. 8 KB DRAM. 3 big blue capacitors, 4 yellow capacitors. Because it was handed-over as an unpopulated board, it looks like, most chips are from later period.


Equipment

No Apple Cassette Interface - just the modern Apple CFF1A card from the 2000's. Triad transformers from 1975. Additional power cable added to the mainboard. Original box.


State

All chips not date correct and/or wrong package. No original PROMs - substitutes from 1983. 4 diodes power section changed. Added wires for alternative power connection.
Working. The circuit board has been signed by Steve Wozniak.

As currently setup:
- The system is housed in a contemporary custom acrylic case
- Keyboard input is provided by a keyboard produced by Wendell Sander in 2014
- Video output is sent to an Apple Monitor III
- Programming can be input via a CFF1A attached to the expansion slot


Video

Working Apple-1
Working Apple-1

Before you click on video links make sure you have read and accepted the disclaimer about Youtube links according to the European Data Protection Law (2016/679).


Last update

Nov 08, 2019


Change log (since March 20, 2018)

Mar 05, 2019: Newly added to the Apple-1 Registry
Mar 09, 2019: Description
Jun 15, 2019: Description of picture(s)/video(s)
Jun 23, 2019: Equipment
Nov 07, 2019: History
Nov 08, 2019: State. Equipment
Nov 08, 2019: 3 picture(s) added
